FIM-3 Fiber Microscope
- Convenient using both for male and female adapters
- Widely used in PON, CWDM, DWDM, SDH, SONET etc.
- Magnification: 250* via 3.5’’ TFT LCD; 400* via 8’’ TFT LCD
- Through the USB 2.0 interface, the PC software can be connected to analyse and record the test results(Optional function)
Description
| Items | Specifications |
|---|---|
| Magnification | 400x (8’’ Monitor), 250x (3.5’’ Monitor) |
| Resolution | 0.5μm |
| Display Screen | 3.5’’ TFT-LCD, 320×240 pixels |
| 8’’ TFT-LCD, 1024×768 pixels | |
| Video Output | NTSC/PAL |
| Power Supply | 3.7V 4500mA / 5V 1A Li-Battery |
| Working Temp | -20 ~+50℃ |
| Storage Temp | -30 ~+60℃ |
| Weight | 1.5kg |
| Standard Accessories: | ||
|---|---|---|
| Inspection Probe x1 | 3.5’’ monitor x1 | 25-U-M x1 |
| 125-U-M x1 | FC-PC-F x1 | SC-PC-F x1 |
| LC-U-F x1 | Recharger | Manual |
| Carrying bag | Li Battery | |
| Optional Accessories: | ||
|---|---|---|
| 25-A-M | 125-A-M | SC-A-F |
| FC-A-F | AV-USB 2.0 Converter | |
| Applications | |
|---|---|
| Tips Type | Function Description |
| 25-U-M | FC/SC/ST/E2000 patch cord UPC connector |
| 125-U-M | LC/MU patch cord UPC connector |
| FC-A-F | FC APC bulkhead |
| 25-A-M | FC/SC/ST/E2000 patch cord APC connector |
| 125-A-M | LC/MU patch cord APC connector |
| FC-PC-F | FC UPC bulkhead |
| SC-PC-F | SC UPC bulkhead |
| LC-U-F | LC UPC bulkhead |
| SC-A-F | SC APC bulkhead |
