FBP7001 Desktop Power Meter
Functions
FBP7001 Desktop power meter is a new generation desktop power meter developed by Grandway. The FBP7001 is also equipped with a wealth of menu design features such as threshold setting, alarm configuration, split ratio, PDL, uniformity, additional loss and other functions, removable external optical power meter probe to meet the majority requirements.
InGaAs
Probe type
850~1700nm
Wavelength range
+5~-75dBm
Test range
±3%
Uncertainly
Description
Features
-Intelligent alarm and threshold allacation
-Buzzer alarm and font color alarm setting
-PDL function test
-Provide RS232 communication function, realize the power monitoring and store the data automatically
Parameter
| Items | Specifications |
|---|---|
| Wavelength Range | 850~1700nm |
| Probe Type | InGaAs |
| Detector Size | Φ2.0mm |
| Test Range | +5~-75dBm |
| Linearity | ±0.04dB(+5~-50dBm) |
| ±0.08dB(-50~-60dBm) | |
| Uncertainty | ±3% |
| Display Resolution | 0.1/0.01/0.001dB |
| Power Supply | AC 220 (50Hz) |
| Temperature | Working temp: -5~40 , Storage temp: -25~70 |
| Dimension/Weight | 235×300×96mm/about 5kg° |
